Digital VAF Meters

Digital VAF Meters

In Stock

Application

  • Model (Bezel Size): SDV-VAF96 (96X96)
  • Display:  3 Rows of 3 digits 7-Segment display Red Color of 0.56″ digit height.
  • Wiring Input: 3Ø – 4 Wire, 1Ø – 2 Wire and 3Ø – 3 Wire (On demand)
  • CT Ratio: Programmable upto 25,000A for /5A CT and upto 5000A for /1A CT
  • PT Ratio: Programmable upto multiplier 5000
  • MEASURED PARAMETER: 3Ø Voltage (L-L, L-N, Avg.), 3Ø Current (IL1, IL2, IL3, IAvg), Frequency, RPM, Run Hour.
  • Measurement Range:
    • Voltage (True RMS) : 11V – 325VAC (VL-N), 19V – 563VAC (VL-L) ,
    • Current (True RMS) : 100mA – 5A AC(6A Max.), Frequency : 10.0 Hz to 88.0 Hz,
    • RPM : 80 – 10560 RPM (For pole selection between 1 – 15) and
    • Run Hour : 0 – 99999.9Hr.
  • Auxiliary Supply Voltage: 230V AC (±20%) , 110V AC (±20%) (to be mentioned with the order).
  • Accuracy: Voltage : ± 1% Current : ± 1%
  • Frequency: ± 0.1Hz, RPM : ± 1% and Run Hour : ± 1%.
  • RESOLUTION:
    • Voltage : 0.1V, 1V, 0.01KV, 0.1KV and 1KV (Depending on PT Ratio),
    • Current : 0.01A, 0.1A, 1A, 0.01KA, 0.1KA (Depending on CT Ratio),
    • Frequency: 0.1Hz, RPM : 1 RPM and Run Hour : 0.1Hr (6 minutes).
  • Mode:  Scroll Enable (Auto) / Scroll Disable (Manual)
  • Order Code: SDV-VAF96
